Strip Light SL180
CRGBW
Collection
Compatible
LUX Strip Lights are an excellent solution to your mood lighting needs, while providing incredible flexibility. Create your own ambience with a…
Features
Collection
Compatible
CRGBW
Product Description
LUX Strip Lights are an excellent solution to your mood lighting needs, while providing incredible flexibility.
Create your own ambience with a subtle blend of colors - full spectrum CRGBW (cold white, red, green, blue, warm white) and white color temperature tuneable (from 2700k to 6500k) available in a single LED strip, with 180 LEDS per meter.
With an IP68 Ingress Protection Rating, the SL180 is suitable for both indoor and outdoor installation on your vessel (above water only).
At just 14.5mm (width), the SL180 can be integrated nearly anywhere onboard and is easily controllable by a momentary switch, with the option to upgrade to full integration with your compatible MFD and/or Lumishore STV2204-i Display (Lumi-Link Command Center required).
LUX Strip Lights are dimmable as standard and powered by a Strip Light Driver.
Specifications
- Available colors:
- Full spectrum CRGBW and white color temperature tuneable in the same strip light
- # of LEDS:
- 180 per meter
- Ingress Protection:
- IP68
- Mechanical installation:
- Adhesive strips and screw clips
- Control options:
- Momentary switch with option to upgrade to full MFD and optional STV2204-i Display connectivity
- Driver:
- LUX Strip Light Driver
- # of LED strips per driver:
- Multiple – up to 10m total
- UV resistant:
- YES
- Salt spray tested:
- YES
Lumi-link
The smartest way to control your Lumishore lights! This award-winning and unrivalled system was designed for ease of installation with a single plug-&-play cable configuration. It is the marine industry’s only plug-and-play module with pre-installed interfaces and lighting options straight out of the box.

Downloads
The product specification sheet and installation manual can be downloaded below. If you require any further information please get in touch.
What It Comes With
- One (1) LUX Strip Light SL180
Controllers & Accessories
- Lumi-Link Command Center (60-0366)
-
Conversion cables and SD cards to compatible MFD’s (plug and play connect):
Garmin Conversion Cable (60-0372)
Simrad/B&G Conversion Cable (60-0372)
Furuno SD Card (60-0377) - LUX Strip and Neon Flex Light Driver (12V)
- Optional STV2204-i Display (60-0369)
-
Strip Light extension cable lengths:
1m (60-0385)
2m (60-0386)
3m (60-0387)
4m (60-0388)
5m (60-0389)
